Coordinated Fire Attack

"The Study of Coordinated Fire Attack Utilizing Acquired Structures,” a multi-year project that is funded by the Federal Emergency Management Agency’s (FEMA) Assistance to Firefighters Grant Program, was designed to increase the understanding of suppression and ventilation tactics to improve firefighter safety and effectiveness. Importantly, occupant safety improves with increases in firefighting effectiveness.

This project extended previous UL Firefighter Safety Research Institute (FSRI)-led studies that examined the impact of specific fire service tactics on fire behavior in isolation and using purpose-built structures. This project specifically expanded upon three prior ventilation studies: “Impact of Ventilation on Fire Behavior in Legacy and Contemporary Residential Construction” [1]; “Effectiveness of Fire Service Vertical Ventilation and Suppression Tactics” [2]; and “Effectiveness of Positive Pressure Ventilation” [3]; a prior suppression study, “Study of the Impact of Fire Attack Utilizing Interior and Exterior Streams on Firefighter Safety and Occupant Survival” [4–6]; and a study on basement fires, “Understanding and Fighting Basement Fires” [7] by applying knowledge that was gained in the laboratory experiments to the streets.

Upon completion of these prior projects, our conversations with firefighters, project technical panel members and our advisory board often converged to a common theme: What happens when you combine these tactics and conduct experiments in real structures? To begin to answer that critical question, the UL FSRI team conducted 40 full-scale, live-fire experiments in residential and commercial acquired structures that included single-family homes, apartments within multi-family dwellings and units within a strip mall—all of which were slated for demolition. Our goal of this supplement is to provide insight into the key findings from the experiments, which are detailed in the following three technical reports:

To safely and successfully conduct these experiments in acquired structures, it was imperative to work with strong and supportive fire department partners. For the 20 single-family experiments, the team traveled to Ohio to work with the Sidney Fire Department and the Beavercreek Township Fire Department. The 13 multi-family experiments were conducted with the Cobb County Fire & Emergency Services in Marietta, GA. Finally, the team returned to Ohio to conduct the seven strip mall experiments with the Fairborn Fire Department. The UL FSRI team sincerely appreciates the men and women of these departments for their tireless effort, professionalism and hospitality during this experimental series.

The authors also wish to express our gratitude to the Shelby County Land Bank and Mary and Bob Nutter for the generous donation of the single-family structures that were used in these experiments. A special thank you goes to the Cobb County Department of Transportation for the generous donation of the apartment buildings that were utilized in the multi-family dwelling experiments. Finally, we thank the city of Fairborn for acquiring the strip mall.

Ventilation and the Impact on Fire Dynamics

To understand the impact of ventilation on fire dynamics, let us first examine the impact of ventilation on the gas flows that are within a structure. The acquired structure experiments confirmed findings from the ventilation experiments in purpose-built structures on the importance of identifying and controlling flow paths that are within a structure (e.g., use of a hoseline, closed doors, fans, etc.). A flow path is the interior volume between a higher-pressure source and a lower-pressure space that’s within the structure and/or atmospheric pressure exterior vent. Fresh air in-flow and smoke exhaust out-flow can be co-located at bidirectional vents or at independent locations via unidirectional vents. Gases that flow within the flow path are driven by pressure, which typically is generated from the production of expanding, high-temperature fire gases (i.e., smoke).

Figure 1. A photograph of an experiment from a kitchen fire in a single-story residential structure that has two open kitchen windows (single-family Experiment 16), and a representation of flows (intake and exhaust). After the rooms of the house open to the fire room have filled with smoke, the kitchen windows served as the only intake and exhaust vents of the flow path (shaded in gray).

Consider the single-story structure that has a kitchen fire and two open kitchen windows that’s shown in Figure 1 (Experiment 16 from the single-family home series). During the growth phase of the fire, bidirectional flows developed through the archways of the kitchen and dining room as higher-temperature, higher-pressure gases flowed toward areas of lower pressure. The area of lower pressure that was created by the increased velocity of the fire plume, combined with the higher-pressure smoke that pushed on the previously motionless gases, led to air flow toward the fire. Once the oxygen that was available for combustion in the air was consumed and smoke filled the dining room and living room, there was limited exchange of gases (predominately smoke), as shown by the small red arrows in Figure 1. At this point, the main source of air for combustion was the intake areas of the kitchen windows. The flow path (shaded in gray) was limited to the kitchen.

Figure 2. A schematic of the gas flow (intake and exhaust). The open front door added a new exterior vent to flow path (shaded in gray), which allowed for additional exchange of combustion gases and ambient air. This exchange provided increased oxygen to the ventilation-limited fire.

Once the front door was opened, the flow of gases through the dining room and living room portion of the flow path increased. An open door is an efficient vent (minimal sill, high lintel) for the exhaust of combustion gases and entrainment of air. Figure 2 shows the bidirectional flow at the doorway after it was opened and shows the changes to the flow of gases within the flow path, particularly between the higher-pressure supply (fire) and lower-pressure vent (open front door).The increase in available oxygen led to an increase in the heat release of the fire. The fire response to changes in ventilation was common across prior laboratory experiments and in each of the acquired-structure experimental series. Therefore, the importance of identifying 1) the fire location, 2) existing intake and exhaust locations (i.e., where the air is coming from), and 3) points of firefighter entry relative to the fire location and open vents as part of a fireground size-up was a key element to tactical considerations that were emphasized in each of the three coordinated fire attack technical reports.

Figure 3. A representation of flow (intake and exhaust) from a bedroom fire within a two-story residential structure that has two open windows in the bedroom with the front door closed. After the two open bedrooms of the second floor filled with smoke, the fire room windows served as the primary intake and exhaust vents of the flow path (shaded in gray).

Let us now examine a two-story residential structure that has a second-floor bedroom fire (Experiment 3 from the single-family series). In this example, two bedroom windows were open and the front door was closed at the time of ignition (see Figure 3). Initially, the flow path included the fire compartment (bedroom), the open second-floor bedrooms, the second-floor hallway and open areas on the first floor. Bidirectional flow was established at both open bedroom windows and through the open fire room door. Similar to the living room and kitchen in the single-story experiment, as smoke filled the additional second-floor bedrooms, the magnitude of gas flows through the respective doorways progressively lessened, leaving the principle intake and exhaust flows between the open windows and the fire.

Smoke filled the open areas of the second floor but had not pushed down into the first floor. With no open vents on the first floor, limited air was able to be pulled up the stairwell. Once the front door was opened by the suppression crew (see Figure 4), the front door became a unidirectional intake vent, and the stairwell became the intake portion of the flow path. Knowledge of the fire location, fire development, open vents and flow path(s) can be leveraged by interior crews to take advantage of the air that’s entrained through the open front door, which can improve conditions for potential occupants who are located in the inlet side of flow path. This benefit only is possible if the suppression crew quickly flows water to begin reducing the hazard of the fire. In both the single-family and multi-family experiments, when the front door was opened (adding to existing ventilation), fire growth was observed, because a more efficient exchange of smoke and air was created.

Figure 4. A representation of flows (intake and exhaust) at that time. The open front door created a unidirectional intake to the flow path (shaded in gray), which allowed for an exchange of combustion gases and ambient air.

Just as it is important to recognize that opening vents can supply oxygen to the fire, firefighters also should understand the impact on path of travel for combustion products. This concept was of particular importance in the multi-family dwellings experiments, because it pertained to toxic gas exposures to potential occupants in the common enclosed stairwell. Figure 5 shows how smoke filled the stairwell and reduced visibility based on the level at which a fire might occur.

Figure 5. Smoke path of travel within the stairwell during below-grade, first-floor and second-floor fires of a multi-family dwelling that has a shared stairwell.

Opening the apartment door to gain access should be thought of as ventilation, in terms of its capability to exhaust from the fire compartment but also for its potential to cause fire growth as well as smoke movement into the stairwell (which could limit the egress for potential occupants in exposure units). Consideration should be given to employ suppression and ventilation tactics that may lessen the flow of combustion gases into shared common spaces whenever feasible. Although not an option for every fire, during both the single-family and multi-family experiments, exterior water application was shown to have a positive impact by lessening of the flow of high-temperature combustion gases out of the fire compartment. Additionally, ventilation tactics, such as door control, positive pressure (e.g.,

Figure 6. Stairwell conditions following entry to the fire apartment for several different tactical options during the multi-family dwelling experiments.

fan) and negative pressure (e.g., hydraulic), that were used either simultaneously with or sequentially post-suppression were shown to limit gas flows into common spaces. Figure 6 shows the conditions in the common stairwell following entry to the fire apartment during the multi-family experiments following different tactical approaches.

Similar fire behavior characterized the strip mall experiments. In each strip mall scenario that was examined, when the additional ventilation area (vertical or horizontal) increased the exhaust of combustion products, it also caused additional air to enter the unit. The additional air added oxygen to a ventilation-limited fire, and the temperatures that were inside of the structure increased. For the experiments that excluded vertical ventilation, a flow path was established between the open front door and the seat of the fire. The flow path began and ended at the front door, with the bottom of the door as the intake and the top of the door as the exhaust. Intake flows circulated as far back as the remaining fuel near the ignition location.

Consider Figure 7, which depicts a cutaway of the unit that was generated from a computational fire model [11] with representative flows that developed as a result of the open front door. The addition of the vertical vents transitioned the front of the structure from a bidirectional flow to a unidirectional intake as the vertical vents were unidirectional exhausts. Note the decreasing magnitude of intake with elevation.

Figure 7. A representation of flows (intake and exhaust) within the strip mall unit following horizontal ventilation (top) and after vertical ventilation (bottom), generated using a computational fire model [11].

Following vertical ventilation, flames were visible at the open vertical vents in two experiments in which suppression was delayed by approximately 90 seconds. However, this was not an indication that all of the heat was being exhausted. In fact, it was an indication that the heat that was within the structure increased, and additional unburned fuels were generated to burn outside of the structure (see Figure 8).

Figure 8. Visible flames following the opening of 32 square feet of vertical ventilation area (left) and 64 square feet of vertical ventilation area (right) for an experiment with suppression delayed until after the completion of ventilation.

Water Usage and Distribution

The water usage discussion focuses on the single-family and multi-family experiments due to the various suppression tactics studied during those series.

In 31 of the 33 residential experiments, a single 1¾-inch hoseline was utilized for initial knockdown and suppression, with either a

Figure 9. Example of improved water dispersion by leveraging exterior water directed off of a window frame.

combination nozzle flowing 150 gpm at 50 psi or a 7/8-inch smooth bore nozzle flowing 160 gpm at 50 psi. For these 31 experiments, the total water that was used during primary suppression of these room and contents fires for both interior suppression and exterior fire control was on average 145 gallons ± 51 gallons that ranged between 73 gallons and 256 gallons. Although this water flow data doesn’t include the water that was used during overhaul and mop-up operations, the primary suppression streams that were used in both single and multiple rooms of fire employing either interior suppression or an exterior fire control technique required total flow that could be attained with fewer than the 300 gallons minimum booster tank capacity on fire apparatus [12]. This does not devalue the need to secure a water supply for your primary suppression apparatus as quickly as possible but highlights that a lot of good can be done with a relatively small amount of water. The two experiments that were outliers include multi-family Experiment 1A, in which the pressurized water extinguisher used less than 5 gallons, and multi-family Experiment 5, where the multi-apartment fire required multiple lines for control and suppression.

Previous research into water application as a part of the fire attack study [4, 6] highlighted the importance of water dispersion within a compartment, regardless of the position of the line relative to the structure (i.e., interior or exterior). In these experiments, alternative means for creating a broken stream improved water distribution within a compartment. A traditional exterior application of water into a fire compartment used a straight stream at a steep angle from a fixed position. This approach maximizes surface/fuel cooling in the compartment and, as a result, is successful generally at reducing the heat release rate of a fire.

Figure 10. Example of improved water dispersion by leveraging interior water directed off of a door frame.

However, because of the momentum of the water, the majority of the water is dispersed around the perimeter of the compartment. Depending on the layout of the fuel within the compartment, the lack of water onto the center of the floor of the compartment can increase the likelihood of regrowth during the transition time for the crew(s) to move to the interior of the structure to complete suppression.

A method for breaking up the hose stream on the upper edge of a window frame in a way that deflects the water spray into the fire room was used as part of the exterior fire control tactic in both the single-family and multi-family components of this experimental series (Figure 9). Applying a broken hose stream into a fire room dropped temperatures throughout the fire compartment and reduced the regrowth potential. In a related manner, an interior suppression crew might be able to get water into a fire compartment much earlier than arriving at the threshold of the fire room door (a hose stream generally should be considered a line-of-sight tool) by using similar principles to the window frame hit (Figure 10). If the nozzle operator is able to determine the location of the door frame, water can be deflected into the fire compartment by manipulating the nozzle up and down along the frame. This causes the stream to break apart, sending some component of the water into the fire compartment and cooling surfaces even before the hose team reaches the room for entry.

Coordination of Fireground Tactics

Across these experiments, a common theme emerged with respect to fireground coordination. When ventilation was provided by opening the front door for access or by conducting horizontal or vertical ventilation and the suppression was delayed, the ventilation led to an increase in the oxygen that was available for combustion. Additional oxygen provided to a vent-limited fire resulted in an increase in the heat release rate of the fire. As the time difference between ventilation and suppression lengthened, there was an increase in severity of the thermal and toxic hazard that was within the structure.

It is important to recognize that as the distance between the fire and the vent location decreased, the response time of the fire to changes in the flow path also decreased. This time can be impacted by other factors, including but not limited to fuel composition, fuel orientation, structure compartmentalization (e.g., closed or open doors) and external wind, among others. Therefore, when creating a new vent in a structure, an appropriate size-up should be conducted with consideration given to the location of the fire and location of the vent.

If water is applied immediately following an opening being made, the removal of heat prior to the renewed source of oxygen reaching the combustibles that still are pyrolyzing can rapidly reduce the temperatures within the structure. Consider an example from the multi-family experiments (Experiment 1C). In this experiment, all vents to the apartment were closed at the time of ignition. Firefighter operations began by venting the fire room (bedroom) window (see Figure 11).

Figure 11. Examples of coordinated suppression one second before start of ventilation, one second after start of ventilation and 20 seconds after start of ventilation. The suppression crew was in place outside of the apartment door (in the enclosed stairwell), made entry to unit and began flowing water within seven seconds of the start of window ventilation.

Within seven seconds, the suppression crew made entry to the fire apartment and began flowing water. Figure 11 shows the conditions 20 seconds after ventilation. Immediately following ventilation, there was an increase in fire room temperatures and visible burning from the bedroom window ventilation. However, as a result of short lag time between ventilation and suppression, there was no noticeable increase in temperatures in any compartment of the apartment or common stairwell that was outside of the fire room. It is important to consider that, whenever possible, ventilation pre-suppression should be limited, potentially to the fire compartment only, and closely timed with the beginning of suppression.

Similarly, in the strip mall experiments, when suppression occurred simultaneously with additional ventilation (Experiment 5), temperatures throughout the compartment and through the ventilation openings decreased upon the start of water flow. Figure 12 shows the visible smoke through the open vertical vent as the crew flowed water at the doorway to the unit. Note the difference compared with Figure 8, where suppression actions lagged the creation of vertical vents.

Figure 12: Exterior conditions through the open vertical vent and at the front door following initial suppression.

Ventilation actions that occurred after the onset of suppression (within 30 seconds) limited additional fire growth in any of the experiments that were conducted as part of this series. In general, the effectiveness of post-suppression ventilation varied substantially between structures, but the experiments in which toxic gas concentrations remained highest for the longest were those in which no timely ventilation actions were performed close to the occupant location. Ventilation post-suppression should be focused on the areas of greatest exposure hazard for potentially trapped occupants.

What's Next

The wide range of variables on the fireground makes it difficult to make definitive statements on the exact time window within which crews must perform suppression and ventilation tactics. However, this project has led to further understanding of the coordinated fireground.

Technical panel members Greg Hubbard, Ray McCormack and Russell Gardner (front row) talk through the scenario of a single-family experiment with Jason Truesdale of the Sidney Fire Department (back row) prior to ignition in Sidney, OH. — Technical panel members Greg Hubbard, Ray McCormack and
Russell Gardner (front row) talk through the scenario of a single-family experiment with Jason Truesdale of the Sidney Fire Department (back row) prior to ignition in Sidney, OH.

Coordination should be thought of as the systematic approach to the implementation of suppression and ventilation tactics. These tactics can occur sequentially or simultaneously with proper communication and coordination to minimize the time lag that’s between them. Firefighting tactics research still is far from complete. Future research should include additional experiments in large-volume structures/fire compartments and improved understanding of thermal and chemical exposures to firefighters. A common research need that was identified in all three phases of the project was additional research into firefighter search and rescue. The coupling of suppression and ventilation tactics for size-up and search and rescue on the residential fireground currently is an area of active research for UL FSRI.

Additional Project Information

The authors of the three technical reports (Craig Weinschenk, Jack Regan, Julie Bryant, Keith Stakes, Nick Dow and Robin Zevotek) thank the entire UL FSRI team for their hard work over the duration of this project. This project required tremendous effort from structure acquisition through instrumentation, experiment execution and data analysis. The authors also thank team member Joshua Crandall for his work capturing many of the photographs that appear throughout this supplement.

For the duration of the project, the UL FSRI team collaborated with the project technical panel (see sidebar) to maximize the impact of each specific experiment for the purposes of improving firefighter safety and firefighter engagement with research. They provided invaluable expertise during the development and planning phase of this project and contributed valuable feedback regarding the project results and conclusions.

Download and read a PDF version of this supplement at firehouse.com/21156932.

Coordinated Fire Attack Technical Panel

Christopher Byrne, Colorado Springs Fire Department
Tony Carroll, District of Columbia Fire and EMS Department
Chad Christensen, Los Angeles County Fire Department
Shea Chwialkowski, Richfield Fire Department
Danny Doyle, Pittsburgh Fire Department
Brad French, Dayton Fire Department
Russell Gardner, Sacramento Metropolitan Fire Department
Scott Gray, Seattle Fire Department
David Guercio, Baltimore City Fire Department
Greg Hubbard, Orange County Fire Rescue
Curt Isakson, Escambia County Fire Rescue
Cody Johnson, Homer Volunteer Fire Department
Frank Leeb, Fire Department of the City of New York (FDNY)
Dennis LeGear, Oakland Fire Department
Stephan Lopez, Dallas Fire-Rescue
Ray McCormack, Fire Department of the City of New York (FDNY)
James Mendoza, San Jose Fire Department
Nicholas Papa, City of New Britain Fire Department
Joe Pronesti, Elyria Fire Department
Richard Riley, Kentland Volunteer Fire Department
Andrew Ruiz, Los Angeles Fire Department
Terrence Sheppard, Chicago Fire Department
Eric Staggs, City of Spokane Fire Department
Chris Stewart, Phoenix Fire Department

The authors also thank the research team from the Illinois Fire Service Institute (IFSI Research) for their assistance throughout the experimental series. Particularly, their expertise in laser diagnostics and skin burn assessments improved the measurement capability of the experiments.
